Fujitsu Image Scanner ScanSnap iX1500

Overview

The ScanSnap iX1500 provides PC and Mac users an effective way to greatly reduce paper clutter, storage space, and security risks associated with unmanaged paperwork at home or the office. For even greater accessibility and usefulness, users can now scan wirelessly to a PC or Mac as well as iOS or Android mobile devices. Compact Color Duplex Scanner for Mac or PC

  • One button searchable PDF creation
  • Advanced paper feeding system
  • Blazing 30ppm color scanningix1500-open
  • 50-sheets Automatic Document Feeder (ADF)
  • Built-in GI microprocessor
  • USB 3.0 (or lower)
  • Scan wirelessly to a PC or Mac
  • Scan wirelessly to iOS or Android mobile devices
  • Comes with Adobe® Acrobat® Standard
  • Faster searchable PDF creation
  • More Quick Menu Productivity
Features

An optimized user experience that keeps evolving

The ScanSnap iX1500 builds upon ScanSnap’s “One Button Simplicity”, taking efficiency to a new level.

Even more intuitive usage achieved by simple operation

You can complete processes from scanning to data utilization with just “one touch” of the 4.3 inch touch screen. Basic tasks such as setup and Wi-Fi configuration, checking scanning statuses and choosing save-to destinations are easy even for first-time users with the touch screen’s easily understandable icon simplicity. Up to 30 pre-configured profiles can be made, optimizing scan workflow.

Profile icon examples

  • Share documents
  • Attach with email
  • Manage business trip expenses
  • Create photo album

Share your ScanSnap for everyone to use

A single unit can be shared with company colleagues and family members with software licenses* for multiple accounts. Since different icon colors can be selected for each user, users can easily tell their profile icons apart from those of other users.

* It comes with multiple software licenses: 4 for ScanSnap Home, 4 for ABBYY FineReader for ScanSnap™ and 1 for Nuance (Win/Mac). Additional licenses may be purchased for ScanSnap Home.

Usability more refined for every user

Designed for ultimate ease of use, the iX1500 transforms all the paper surrounding you with valuable information and adds more productivity to your lifestyle.

Refined and aesthetic form

The scanner’s adaptable and aesthetic design enables it to blend into any space, so it can stay where it is used the most, your office, living room or study room.

Create files quickly

Simply open the document chute and ScanSnap is ready to go. Scan single and double sided documents with ease at a speedy 30 sheets per minute*1. When choosing “Fast” startup*2, you can start scanning even faster.

*1 Image quality: Best mode (color/grayscale at 300 dpi; B&W at 600 dpi).
*2 Power consumption increases with “Fast” startup.

Scan any document

Scan documents larger than the typical A4 size that need to be folded in half, envelopes and much more with Manual Scan Mode. Documents that are typically difficult to scan in Normal Scan Mode can now be captured without any issues.

Effortlessly scan small documents with the Receipt Guide. No need to be concerned about fixing receipts and business cards that tend to curl or skew. Designed to be a comfortable fit even when the cover is closed, it dramatically reduces the handling of documents before hitting the scan button.

Versatile paper handling

With professional grade feeding technology and ultrasonic sensors, the iX1500 handles multi-page documents with ease, and can additionally detect and alert you of multi-feeding errors.

Have images clean all the time

Receive notifications on the touch screen whenever Dust Detection spots dust that may result in streaked images. Maintenance notification beforehand enables you to reduce the hassle of time-consuming rescans.

Even if streaks happen to appear on scanned images, Streak Reduction function removes them to produce clean images.

Scan anywhere you want whenever you want

Connect the iX1500 to your computer or smart device (both iOS and Android)*1 in your office and at home, using existing Wi-Fi environments with Access Point Connect Mode*2. Connecting is also possible in environments without Wi-Fi using Direct Connect Mode, as the scanner itself functions as an access point. Supporting 5 GHz Wi-Fi*3, it ensures smooth data transmission.

  • *1 When using smart devices, ScanSnap Connect Application is required.
  • *2 Access Point Connect Mode requires a Wi-Fi access point or router.
  • *3 Availability of 5 GHz Wi-Fi may vary depending on region. 5 GHz Wi-Fi is not available with Direct Connect Mode.

Best experience with ScanSnap Home

ScanSnap Home combines all your favorite functions into one and is the ultimate platform to utilize scanned data in various ways. Easily manage, edit and utilize data from documents, business cards, receipts and photos with the software. You can scan large volumes of various types of documents from color photos to double-sided landscape documents with a host of intelligent automatic image processing functions.

Specifications
Product name ScanSnap iX1500
Scanner type ADF (Automatic Document Feeder)/Manual Feed, Duplex
Scanning color mode Color, Grayscale, Monochrome,
Automatic (Color/Grayscale/Monochrome*1 detection)
Image sensor Color CIS x 2 (Front x 1, Back x 1)
Light source 3 Color LED (Red/Green/Blue)
Optical resolution 600 dpi
Scanning speed*2 (A4 portrait) Auto mode (Default)*3 Simplex/Duplex: 30 ppm
Normal mode Simplex/Duplex: 30 ppm
(Color/Grayscale: 150 dpi, Monochrome: 300 dpi)
Better mode Simplex/Duplex: 30 ppm
(Color/Grayscale: 200 dpi, Monochrome: 400 dpi)
Best mode Simplex/Duplex: 30 ppm
(Color/Grayscale: 300 dpi, Monochrome: 600 dpi)
Excellent mode*1 Simplex/Duplex: 8 ppm
(Color/Grayscale: 600 dpi, Monochrome: 1,200 dpi)
Document Normal scan Minimum: 50.8 x 50.8 mm (2 x 2 in.) Maximum: 216 x 360 mm (8.5 x 14.17 in.)
size Manual scan A3, B4, 279 x 432 mm (11 x 17 in.)
Long paper scanning*4 3,000 mm (863 mm in 32-bit)
Smart Device: 863 mm (Duplex), 1,726 mm (Simplex)
Paper weight (Thickness) 40 to 209 g/m2 (11 to 56 lb)
A8 size or less: 128 to 209 g/m2 (34 to 56 lb)
Cards: 0.76 mm or less (Compliant with the ISO7810 ID-1 type) (Includes embossed cards in landscape orientation)
ADF capacity*5 50 sheets (A4, 80 g/m2 or 20 lb)
Interface USB USB 3.1 Gen1 / USB 3.0 / USB 2.0 / USB 1.1 (Connector Type: Type-B)*6
Wi-Fi IEEE802.11a/b/g/n/ac Frequency band: 2.4 GHz / 5 GHz*7
Wi-Fi Interface Access Point Connect Mode (Infrastructure mode)*8 Direct Connect Mode (Ad-hoc mode)*9
LCD 4.3 in. color TFT touch screen
Power requirement AC 100 to 240 V, 50/60 Hz
Power Operating 17 W or less
consumption Sleep mode (USB connected) 1.5 W or less
Sleep mode (Wi-Fi connected) 1.6 W or less
Operation environment Temperature: 5 to 35 °C (41 to 95 °F)
Relative humidity: 20 to 80% (Non-condensing)
Dimensions (W x D x H)*10 292 x 161 x 152 mm (11.5 x 6.3 x 6.0 in.)
Device weight 3.4 kg (7.5 lb)
Environmental compliance ENERGY STAR®/RoHS
Multifeed detection Overlap detection (Ultrasonic sensor), Length detection
Driver ScanSnap Home (ScanSnap specific driver) •Windows: Does not support TWAIN/ISIS™ • Mac OS: Does not support TWAIN

‘1 Available only when connecting to a computer. *2 Scanning speeds may vary due to the system environment used. *3 Scans will be made in “Best mode” if shorter sides are less than 105 mm and in “Better mode” if not. *4 Available in all modes except for “Excellent mode” *5 Maximum capacity varies, depending upon paper weight and whether optional Receipt Guide is installed. When Receipt Guide is installed, ADF capacity is limited to 15 sheets. *6 Some computers do not recognize the ScanSnap when it is connected to a USB 3.1 Gen1/3.0 port. In this case, please use a USB 2.0 port. *7 Availability of 5 GHz Wi-Fi may vary depending on region. *8 Access Point Connect Mode requires a Wi-Fi access point or router. *9 5 GHz Wi-Fi is not available with Direct Connect Mode. *10 Excluding the stacker and other external attachments.

ScanSnap iX1500 System Requirements

  • Windows
Operating systems Windows 10 (32-bit / 64-bit)*1 Windows 8.1 (32-bit / 64-bit)*1 Windows 7 (32-bit / 64-bit)
Hardware

requirements*2

CPU*3 Intel® Celeron 1.8 GHz (2core) or higher (Recommended: Intel® Core™ i5 2.5 GHz or higher)
Memory capacity*3 2 GB or more (Recommended: 4 GB or more)
Display resolution 1,024 x 768 pixels or more
Disk capacity*4 3.8 GB or more of free hard disk space

*1 Operate Windows in desktop mode. *2 The ScanSnap device may not work if the connected computer does not meet these requirements. *3 Scanning speeds may drop if the recommended CPU, memory capacity and USB 1.1 requirements are not met. *4 Microsoft .NET Framework 4.7 will be installed (requires 4.5 GB of disk space) together with ScanSnap Home for systems that do not have .NET Framework 4.7 installed.

*Please refer to the ScanSnap website for the latest support information of the driver and applications. Compatibility may differ depending on the software’s version.*The system requirements may change depending on the duration of support and the support policy of the companies that make the software.

  • Mac
macOS v.10.14
Operating systems macOS v.10.13
macOS v.10.12*1
Hardware

requirements*2

CPU*3 Intel® Core i5 1.4 GHz or higher (Recommended: Core i5 2.5 GHz or higher)
Memory capacity*3 2 GB or more (Recommended: 8 GB or more)
Display resolution 1,024 x 768 pixels or more
Disk capacity 2.0 GB or more of free hard disk space

*1 macOS v10.12.4 or later is required. *2 The ScanSnap device may not work if the connected computer does not meet these requirements. *3 Scanning speeds may drop if the recommended CPU, memory capacity and USB 1.1 requirements are not met.

*Please refer to the ScanSnap website for the latest support information of the driver and applications. Compatibility may differ depending on the software’s version *The system requirements may change depending on the duration of support and the support policy of the companies that make the software.

Accessories

Accessories

Part Number Description
Consumables
Roller Set(1) PA03656-0001 Lifetime: Every 200,000 sheets or one year
(For ScanSnap iX1500 or iX500)
Cleaner F1 PA03950-0352 100 ml bottle
For use on the Brake roller and Pick roller
Cleaning Wipe PA03950-0419 24 packets
For use on the Brake roller and Pick roller
Cleaning Paper CA99501-0012 10 sheets
Use this non-woven sheet with Cleaner F1
Options
ScanSnap Home Additional License (1 License) PA43404-B043 1 additional license for ScanSnap Home
Carrier Sheet(2) PA03360-0013 Contains 5 carrier supporting photographs and various document sizes
(For ScanSnap iX1500, iX500, iX100, S1100i)
Photo Carrier Sheet PA03770-0015 Contains 5 sheets supporting photographs (E-size, L-size, King-size), postcards and business cards
ScanSnap Bag(3) PA03951-0651 Stores the ScanSnap iX1500/iX500 and accessories
  1. These recommended lifetimes are for 80 g/㎡ (20 lb) A4 sized documents. Therefore, appropriate replacement lifetimes may vary for other document types.
  2. Although ScanSnap Carrier Sheets have a listed lifespan of 500 scans, the lifespan may vary with usage. ScanSnap Carrier sheets are intended to scan paper documents with weights of 127 g/m2 or less. They also support the scanning of folded documents that are as large as 216 x 297 mm.

*We recommend the use of our genuine products for the consumables. Failures, troubles, and damage of this product resulting from the use of consumables other than our genuine products are subject to repair fees even within the warranty period.
